Imaging Equipment

OEC 9800 Plus

Versatile. Dependable. Easy to use.
GE HealthCare Mobile C-Arm Product.

A fixture in many ER, OR, ICU, pain management, and outpatient settings, the OEC 9800 Plus flexible C-arm is a dependable, multi-purpose workhorse. Produce high quality images with ease across a variety of cases from simple to complex including orthopedic, pain management, spine, and even peripheral vascular procedures. Three C-arm configurations — 9″, 12″, and Super C — are available to meet specific clinical needs. OEC’s SmartView pivot joint allows the C-arm to move freely off axis and into the precise angle needed, even in tight spaces. Super C offers 55° overscan to achieve steep angle images.

Hardware:

  • 9” or 12” image intensifier
  • 15 or 30 frames per second
  • 15kW, 60 kHz generator
  • PreView™ Tungsten rotatable double leaf collimator
  • High-level pulsed fluoroscopy
  • Digital cine pulse mode
  • Dual monitor video display console

Software:

  • AutoTrak™ Automatic Brightness Stabilization
  • Smart Window
  • Smart Metal
  • Real-time digital subtraction
  • Roadmapping
  • 1k x 1k x 16-bit image processing

Download the OEC 9800 Product Brochure


High-quality Images
  • he penetrating power of the 9800 Plus 15KW rotating anode X-ray tube, coupled with the tube cooling system and small focal spot, enables dense anatomy penetration while the design facilitates longer fluoroscopy on time for high-quality images in almost any situation.
  • Smart Metal intuitively adjusts brightness and contrast to improve image quality when metal is present in the X-ray field.
  • Smart Window dynamically senses the collimator position and automatically optimizes images.
  • During live fluoro, AutoTrak detects the subject anatomy (even if it’s moving), stabilizes the image, and reduces dark images and burnout.

Ease of Use
  • Point-and-shoot technology — simply align the anatomy and shoot the image.
  • Intuitive, familiar software keeps things simple, and quick.
  • Convenient dual-side C-arm controls.
  • Built-in smart features – Smart Metal, Smart Window, AutoTrak – automatically produce sharp images in challenging cases.
  • Compact durable frame provides free space and C-arm depth for unobstructed imaging and patient access.
  • Locks, levers, and buttons — along with counterbalance and friction controls — make precise C-arm operation easy.
Standard Accessories
  • 24”x 70” phenolic tabletop with steel frame
  • Patient weight capacity: (181 kg) 400 lbs
  • Convenient dual-side C-arm controls.
  • Up to 5 degrees of motor driven motion:
    • Trendelenburg tilt: 16°
    • Lateral tilt: 17°
    • Height adjustment: 29” to 39”
    • Longitudinal travel (head to foot): 10” (+/- 5”)
    • Lateral travel (side to side): 10” (+/- 5”)
